The Perlisten Audio R7t Tower Speaker achieves acoustic truth through advanced driver technology and optimal enclosure design. Experience pure sound delivered with minimal distortion, perfect for any audiophile's listening environment.
The R7t Tower Speaker utilizes a DPC (Directivity Pattern Control) array consisting of three 26mm silk dome tweeters and four 165mm woofers with proprietary HPF (High-Performance Fiberglass) pulp diaphragms. This configuration ensures excellent control of directivity down to 500Hz, facilitating accurate sound reproduction and high fidelity across frequency ranges. The enclosure design supports both bass reflex and acoustic suspension configurations, enabling the speaker to maintain rich and dynamic bass while providing smooth midrange and treble responses. The sensitivity rating of 90.0 dB along with a 4Ω nominal impedance optimally aligns the R7t for use with amplifiers ranging from 100 to 400 watts RMS, allowing high sound pressure levels with minimal harmonic distortion. Moreover, the frequency response from 80Hz to 20kHz with a ±1.5dB linearity, coupled with robust build quality, ensures this speaker can perform well in larger listening environments.
Key Features
-
DPC Array Technology: Features a triad of 26mm silk dome tweeters providing precise directivity control, ensuring cohesive sound dispersal and enhanced imaging.
-
High-Performance Woofers: The 165mm HPF pulp woofers are engineered for high excursion and low distortion, delivering deep and dynamic bass response.
-
Flexible Enclosure Design: Stands as both a bass reflex and acoustic suspension speaker to suit varying preferences, optimizing bass performance from 19Hz to 30Hz depending on the configuration.
-
THX Certification: Meets rigorous standards for high-fidelity audio reproduction, ensuring quality performance in home theater environments.
-
Robust SPL Capabilities: Achieves a peak sound pressure level of 116.0dB (100-20kHz) with minimal harmonic distortion, providing an impactful listening experience across all dynamics.
Technical Specifications
- Enclosure Alignment: 4-way bass reflex / acoustic suspension
- Driver Complement: DPC Array: 26mm(3) Silk dome, Woofers: 165mm(4) HPF diaphragms
- Sensitivity: 90.0dB/2.83v/1.0m
- Impedance: 4Ω nominal / 3.1Ω min
- Response Linearity: 80 - 20kHz +/-1.5dB window
- Frequency Response (-10dB): Bass reflex: 27-32kHz, Acoustic suspension: 38-32kHz
- Typical In-Room Bass Extension: Bass reflex: 19Hz, Acoustic suspension: 30Hz
- Dimensions (HxWxD): 1268x230x350mm (49.9x9.0x13.7")
- Weight: 48.0 kg (105.6 lbs.)
- Recommended Amplifier Power: 100-400W RMS
- SPL Capability (100-20kHz): 116.0dB peak <3%-2nd, 3rd Harmonics
- Certification: THX Dominus, THX Ultra
- Available Finishes: Piano black
